Specifications of UT33+ Series Palm Size Multimeters
Inhouse product
Specifications of UT33+ Series Palm Size Multimeters
Specifications | Range | UT33D+ | ||
DC voltage (V) | 200mV/2V/20V/200V/600V | ±(0.5%+2) | ||
AC voltage (V) | 600V | |||
200V/600V | ±(1.2%+3) | |||
DC current (A) | 10A | |||
200μA/200mA/10A | ||||
2000μA/20mA/200mA/10A | ±(1%+2) | |||
AC current (A) | 10A | |||
Resistance (Ω) | 200Ω/2kΩ/20kΩ/200kΩ /2MΩ/20MΩ/200MΩ | |||
200Ω/2kΩ/20kΩ /200kΩ/20MΩ/200MΩ | ±(0.8%+2) | |||
200Ω/2kΩ/20kΩ /200kΩ/20MΩ | ||||
Capacitance (F) | 2mF | |||
Temperature | -40℃~1000℃ | |||
-40℉~1832℉ | ||||
Features | ||||
Display count | 2000 | |||
Auto power off/Auto backlight off | √ | |||
Diode test/Continuity buzzer | √ | |||
2m drop test/ Test probe holder | √ | |||
Range selection | Manual | |||
Battery test | ||||
NCV | √ | |||
General Characteristics | ||||
Power | 1.5V battery (R03) x 2 | |||
Display | 66mm x 51mm | |||
Product net weight | Red and grey | |||
Product color | 206g (batteries included) | |||
Product size | 134mm x 77mm x 47mm | |||
Standard accessories | Batteries, test leads, K-type thermocouple (UT33C+) | |||
Standard individual packing | Gift box, English manual | |||
Standard quantity per carton | 60pcs | |||
Standard carton measurement | 640mm x 310mm x 350mm | |||
Standard carton gross weight | UT33A+: 18.6kg; UT33B+: 19.4kg; UT33C+: 20.6kg; UT33D+: 19.8kg |
